DRAWING AND BLANKING
Description
We have a wide range of products for each specific application, from the simplest to the most sophisticated pressing and cutting operation. To suit any type of application, Bellini developed 3 categories of fluids: straight, the X-Draw line, water miscible, the Torma Draw line, and bio based, the X-Draw Bio line.
X-Draw GL is our latest line of vanishing gels. The most distinguishing feature of these fluids is that they leave the surface of the finished part clean.
FEATURES
The pressing and blanking sector is characterized by very specific needs and requirements. The high level of customization of Bellini products allows us to respond to any need.
Bellini’s drawing and blanking fluids are high quality and technologically advanced products. They ensure better surface finishings, a longer press life and a greater washability of the finished parts. This feature definitely contributes to the reduction of total operating costs.

Products
HOT DRAW 06-320
E’ un lubrificante biodegradabile, ad elevato Indice di Viscosità, per la lubrificazione a perdere delle guide e delle slitte di scorrimento. E’ formulato con particolari esteri di origine naturale e con un accurato pacchetto di additivi senza ceneri contro l’usura, l’ossidazione, la ruggine e la schiuma. Esso garantisce:
– un elevato indice di viscosità ad alta resistenza meccanica proprio della base impiegata, senza aggiunta di additivi miglioratori, per una costanza prestazionale anche in condizioni gravose di esercizio;
– un molto basso naturale punto di scorrimento;
– una eccezionale protezione contro l’usura, la corrosione, la ruggine, la schiuma;
– un ottimo potere EP ed anti stick-slip;
– compatibilità con tutti i metalli e le loro leghe impiegati nei normali macchinari;
– è compatibile con gli elastomeri di migliore qualità comunemente presenti sul mercato quali:
– gomma fluorurata (per esempio Viton);
– PTFE (per esempio Teflon);
– gomma butadiene acrilo-nitrile (alto nitrile): NBR-HNBR;
– gomma fluorosiliconica;
– gomma siliconica o altre gomme comunque compatibili con gli esteri.
Applicazione
E’ specificamente formulato per impianti operanti in severe condizioni di esercizio che richiedono oli biodegradabili altamente prestazionali per basse e bassissime temperature ambientali ed Estreme Pressioni di esercizio. Particolarmente indicato per macchinari operanti in ambiente esterno.
I dati riportati non costituiscono specifica
HOT DRAW 06-460
E’ un lubrificante biodegradabile, ad elevato Indice di Viscosità, per la lubrificazione a perdere delle guide e delle slitte di scorrimento. E’ formulato con particolari esteri di origine naturale e con un accurato pacchetto di additivi senza ceneri contro l’usura, l’ossidazione, la ruggine e la schiuma. Esso garantisce:
– un elevato indice di viscosità ad alta resistenza meccanica proprio della base impiegata, senza aggiunta di additivi miglioratori, per una costanza prestazionale anche in condizioni gravose di esercizio;
– un molto basso naturale punto di scorrimento;
– una eccezionale protezione contro l’usura, la corrosione, la ruggine, la schiuma;
– un ottimo potere EP ed anti stick-slip;
– compatibilità con tutti i metalli e le loro leghe impiegati nei normali macchinari;
– è compatibile con gli elastomeri di migliore qualità comunemente presenti sul mercato quali:
– gomma fluorurata (per esempio Viton);
– PTFE (per esempio Teflon);
– gomma butadiene acrilo-nitrile (alto nitrile): NBR-HNBR;
– gomma fluorosiliconica;
– gomma siliconica o altre gomme comunque compatibili con gli esteri.
Descrizione
E’ specificamente formulato per impianti operanti in severe condizioni di esercizio che richiedono oli biodegradabili altamente prestazionali per basse e bassissime temperature ambientali ed Estreme Pressioni di esercizio. Particolarmente indicato per macchinari operanti in ambiente esterno.
I dati riportati non costituiscono specifica.
HOT DRAW 09-220
È un olio lubrificante piuttosto viscoso, specificatamente formulato per l’impiego nella deformazione a caldo dei metalli. È ottenuto da basi minerali particolarmente selezionate e raffinate al solvente, in miscela con grafite colloidale molto finemente micronizzata e con un complesso di additivi che ne assicurano la massima disperdenza. Presenta le seguenti caratteristiche:
– Eccellente stabilità, contro la formazione di depositi e sedimenti nei contenitori.
– Proprietà lubrificanti eccezionali, anche alle più alte temperature.
– Uno spiccato potere bagnante e distaccante, soprattutto nel caso di produzione di componenti a geometria complessa.
– Altissimo punto di infiammabilità.
– Consumi molto ridotti.
Applicazione
E’ particolarmente indicato nello stampaggio a caldo delle leghe gialle e degli acciai con l’impiego di presse meccaniche e magli. Può essere applicato mediante pistole a spruzzo manuali, aerografi e apparecchi spray automatici e semiautomatici.
I dati riportati non costituiscono specifica.
HOT DRAW 09-460
Description
It a lubricant oil, rather viscous, formulated in detail for hot deformation of metals. It is made from particularly selected and solvent-refined mineral bases, in mixture with micronized colloidal graphite and an additive complex, which allow the product to be easily dispersable.
It has the following features:
- Excellent stability, against deposit and sediment formation in the containers;
- Excellent lubricant properties, even at the highest temperatures;
- A strong wetting and detaching power, above all when complex geometry components are produced;
- Very high flash point;
- Very reduced consumes.
Application
HOT DRAW 09-460 is particularly used for hot forging of yellow alloys and steels, using mechanical press and power hammers.
It can be used through manual spray pistols, aerographs and automatic and semi-automatic spray equipment.
Data do not constitute any specification.
HOT DRAW 09-680
È un olio lubrificante piuttosto viscoso, specificatamente formulato per l’impiego nella deformazione a caldo dei metalli. È ottenuto da basi minerali particolarmente selezionate e raffinate al solvente, in miscela con grafite colloidale molto finemente micronizzata e con un complesso di additivi che ne assicurano la massima disperdenza. Presenta le seguenti caratteristiche:
– Eccellente stabilità, contro la formazione di depositi e sedimenti nei contenitori.
– Proprietà lubrificanti eccezionali, anche alle più alte temperature.
– Uno spiccato potere bagnante e distaccante, soprattutto nel caso di produzione di componenti a geometria complessa.
– Altissimo punto di infiammabilità.
– Consumi molto ridotti.
Applicazione
E’ particolarmente indicato nello stampaggio a caldo delle leghe gialle e degli acciai con l’impiego di presse meccaniche e magli. Può essere applicato mediante pistole a spruzzo manuali, aerografi e apparecchi spray automatici e semiautomatici.
I dati riportati non costituiscono specifica.
HOT DRAW 09-860
È un olio lubrificante piuttosto viscoso, specificatamente formulato per l’impiego nella deformazione a caldo dei metalli. È ottenuto da basi minerali particolarmente selezionate e raffinate al solvente, in miscela con grafite colloidale molto finemente micronizzata e con un complesso di additivi che ne assicurano la massima disperdenza. Presenta le seguenti caratteristiche:
– Eccellente stabilità, contro la formazione di depositi e sedimenti nei contenitori.
– Proprietà lubrificanti eccezionali, anche alle più alte temperature.
– Uno spiccato potere bagnante e distaccante, soprattutto nel caso di produzione di componenti a geometria complessa.
– Altissimo punto di infiammabilità.
– Consumi molto ridotti.
Applicazione
E’ particolarmente indicato nello stampaggio a caldo delle leghe gialle e degli acciai con l’impiego di presse meccaniche e magli. Può essere applicato mediante pistole a spruzzo manuali, aerografi e apparecchi spray automatici e semiautomatici.
I dati riportati non costituiscono specifica.
HOT DRAW 2-320
It is a quite viscous lubricant, specifically formulated for the hot-deformation of metals.
It is obtained by mineral bases particularly selected and solvent refined, in mixture with colloidal graphite very finely micronized and with a complex of additives which ensure the maximum leakage conductance.
It has the following characteristics:
- excellent stability, against the formation of deposits and sediments in the containers;
- outstanding lubricant properties, even at the highest temperatures;
- a strong wetting and detaching power, above all in the case of production of components with a complex geometry.
- very high flash point;
- very reduced consumptions.
Application
It is particularly indicated in the hot forming of the yellow alloys and steels with the use of mechanical presses and hammers.
It can be used through manual spray guns, aerographs and automatic and semi-automatic spray instruments.
Data do not constitute any specification.
HOT DRAW 2-460
It is a quite viscous lubricant, specifically formulated for the hot-deformation of metals.
It is obtained by mineral bases particularly selected and solvent refined, in mixture with colloidal graphite very finely micronized and with a complex of additives which ensure the maximum leakage conductance.
Features:
- excellent stability, against the formation of deposits and sediments in the containers;
- outstanding lubricant properties, even at the highest temperatures;
- a strong wetting and detaching power, above all in the case of production of components with a complex geometry;
- very high flash point;
- very reduced consumptions.
Application
It is particularly indicated in the hot forming of the yellow alloys and steels with the use of mechanical presses and hammers. It can be used through manual spray guns, aerographs and automatic and semi-automatic spray instruments.
Data do not constitute any specification.
HOT DRAW 2-680
È un lubrorefrigerante intero, molto fluido, esente da olio minerale, formulato per operazioni di lappatura, levigatura, asportazione truciolo e rettifica di materiali ferrosi e non ferrosi. È formulato con materie prime di ultima generazione, costituite da esteri totalmente saturi e di sintesi, con additivi atti ad ottimizzare le prestazioni di taglio. E’ molto alta la compatibilità igienico-sanitaria ed ambientale.
Esso garantisce:
- Assenza di fumi e vapori in lavorazione
- Un elevato punto di infiammabilità per operazioni in assoluta sicurezza
- Un’ottima scorrevolezza anche a basse temperature ed un’eccezionale potere bagnante, per cui l’olio si disperde sulla superficie metallica in modo rapido ed uniforme
- Ottimo potere untuosante, EP e lubro-distaccante per finiture di qualità
- Buona resistenza all’ossidazione ed alla ruggine
- Buon potere antiusura
- Bassa temperatura dei pezzi lavorati
- Sfrido ben frantumato e spezzettato
- Un ottimo potere antisaldante di taglio
- Completa biodegradabilità
- Massima tollerabilità da parte degli operatori in quanto non contiene nè componenti nocivi nè irritanti.
Il prodotto è esente da composti clorurati e/o solforati, e non contiene idrocarburi policiclici aromatici (IPA)
Descrizione
Tutte le operazioni, anche gravose, con sistemi sia di lubrificazione tradizionale a getto che di tipo minimale spray, su materiali ferrosi e non ferrosi, titanio compreso, dove sia richiesto un prodotto ad alto grado di fluidità. Idoneo anche per operazioni di lappatura e rettifica ad elevato rendimento di acciai, in particolare acciaio inox, metalli duri, grafiti; ottimo con tutti i tipi di mole incluse quelle in CBN.
HOT DRAW 2-860
It is a quite viscous lubricant, specifically formulated for the hot-deformation of metals.
It is obtained by mineral bases particularly selected and solvent refined, in mixture with colloidal graphite very finely micronized and with a complex of additives which ensure the maximum leakage conductance.
It has the following characteristics:
- excellent stability, against the formation of deposits and sediments in the containers;
- outstanding lubricant properties, even at the highest temperatures;
- a strong wetting and detaching power, above all in the case of production of components with a complex geometry.
- very high flash point;
- very reduced consumptions.
Application
It is particularly indicated in the hot forming of the yellow alloys and steels with the use of mechanical presses and hammers. It can be used through manual spray guns, aerographs and automatic and semi-automatic spray instruments.
Data do not constitute any specification.
TL 60/E
It is a viscous fluid, made of a mixture of chlorinated compounds and anti-oxidants additives, polar additives and anticorrosive.
These components allow to make processing of plastic deformation extremely heavy, in particular of stainless steels and hard and extra-hard alloyed steels.
Features:
- excellent surface finishing, also for pieces of complex geometry;
- long lasting dies;
- excellent smoothness of the surfaces, while deforming.
Application
Drawing and deep pressing, deep-drawing, extrusion, cold-drawing, lapping of alloyed high resistant steels, in particular inox.
It can be applied by brush, rollers, rubber pad etc…
Data do not constitute any specification.
TORMA DRAW ABS
Il TORMA DRAW ABS è un fluido di sintesi lubrificante che ha come specifico campo di applicazione quello della deformazione a freddo della lamiera. Per questo uso il prodotto si dimostra innovativo e vantaggioso innanzitutto per la proprietà di permettere un notevole incremento della vita degli stampi. Esso in effetti è dotato delle esatte proprietà richieste per queste lavorazioni e cioè:
- assenza di olio minerale;
- potere untuosante per consentire agli utensili una sufficiente proprietà antiusura;
- compatibilità col cobalto (legante del metallo duro), per garantire l’integrità degli stampi;
- elevato potere bagnante e assenza di residui collosi così da ottenere, con la assenza di micro-sfridi e morchie nel punto di lavoro, il minimo di effetto abrasivo sul filo degli stampi;
- elevato potere antiruggine e passivante dell’ossidazione;
- assenza di sostanze (derivati clorurati, ecc.) chimicamente attive sul film ricoprente il lamierino, a salvaguardia dell’omogeneità delle sue caratteristiche superficiali;
- assenza di residuo secco-colloso.
Applicazione
Tutte le operazioni di deformazione a freddo dei materiali ferrosi acciai e delle leghe di alluminio con vari contenuti di Silicio, in particolare quando è richiesta una specifica compatibilità del prodotto con plastiche in ABS. Correttamente diluito in acqua è utilizzabile in operazioni di taglio dove è prevista la nebulizzazione del fluido. E’ idoneo anche per lavorazioni di lamiera zincata.
I dati riportati non costituiscono specifica
TORMA DRAW LM
TORMA DRAW LM is a synthetic and lubricant fluid. It can be easily dispersed in water, making a translucent, stable and semi-transparent emulsion. Its specific application is cold die forming of plate sheets. The product is innovative and convenient, thanks to its property of increasing dies life.
It has the following features, which are suitable in the operations mentioned above:
- No mineral oil;
- Oily power for a good anti-wear and EP property;
- High wetting power, no tacky residual, no micro-swarf or sludge while working and minimum abrasive effect on dies edge;
- Good anti-rust and anti-oxidant power;
- No active components (e.g. chlorinated compounds) on plates surface, in order to save its characteristics;
- No dry-tacky residual.
Application
Pressing, cold forging and die forming of ferrous materials (steel) and high-content silicon alloys (>7%). When diluted in water al the correct percentage, it can be used in cutting operations, where fluid nebulization is expected.
Data do not constitute any specification.
TORMA DRAW LM AW/PL
TORMA DRAW LM AW/PL is a synthetic and lubricant fluid. It can be easily dispersed in water, making a translucent, stable and semi-transparent emulsion. Its specific application is cold die forming of plate sheets. The product is innovative and convenient, thanks to its property of increasing dies life.
It has the following features, which are suitable in the operations mentioned above:
- No mineral oil;
- Oily power for a good anti-wear and EP property;
- High wetting power, no tacky residual, no micro-swarf or sludge while working and minimum abrasive effect on dies edge;
- Good anti-rust and anti-oxidant power;
- No active components (e.g. chlorinated compounds) on plates surface, in order to save its characteristics;
- No dry-tacky residual.
Application
Pressing, cold forging and die forming of ferrous materials (steel) and high-content silicon alloys (>7%). When diluted in water al the correct percentage, it can be used in cutting operations, where fluid nebulization is expected.
Data do not constitute any specification.
TORMA TF2 PL
TORMA TF2 PL is a metalworkingfluid used for lamination blanking. The product is innovative and advantageous, thanks to its property to increase stamps life.
It has the following properties:
- No mineral oil;
- Greasing power in order to obtain a sufficient anti-wear property. EP PROPERTIES;
- Cobalt compatibility (hard metal alloy) in order to ensure dies integrity;
- High wetting power and no sticky residual;
- No micro scraps and sludge;
- Minimum abrasive effect on the stamps;
- High anti-rust power, even in vapour phase;
- No chemical active substances (Chlorine derivatives, etc.) on the lamination film, in order to safe its dielectric characteristics;
- No dry-sticky residual, which helps the correct management of lamination package formation.
Application
1) Percentage Use
The percentage use of TORMA TF2 PL ranges, according to different factors as water hardness for the emulsion, required protection, etc.
- Average percentage use: 6-8%
2) Emulsion formation
TORMA TF2 PL solubilizes easily and quickly, both manual and through a blender. In the first case, is fundamental to pour the product in the water (not vice versa), in order to let TORMA TF2 PL spread uniformly. This operation, if made slowly and with regular shaking, will ensure to the emulsion a better stability and will give value to the product characteristics. TORMA TF2 PL correctly solubilizes also through aspiration and volumetric blender, with the recommendation to periodically verify the
calibration and the correct efficiency.
Data do not constitute any specification.
X-DRAW 160 CL
It’s an oil, strongly added with additives, for deep drawing of high-alloy steels and stainless steels, based on organic active principles containing chlorine, mineral oil, synthetic and natural greases, antioxidants and metallic passivators.
The liquid is clear, of a very moderate smell, viscous on average, adhesive, with an exceptional detaching and anti-welding power. It has a high stability to ageing.
Application
Indicated in the most severe operations of drawing and punching, at very high pressures and high and complex deformation, of high-alloy steels, such as nickel-chromium and chromium-manganese sheet metal, stainless steel, etc. .., with thickness up to 2 mm.
Data do not constitute any specification.
X-DRAW 160 CL-SP
It’s an oil, strongly added with additives, for deep drawing of high-alloy steels and stainless steels, based on organic active principles containing chlorine, mineral oil, synthetic and natural greases, antioxidants and metallic passivators.
The liquid is clear, of a very moderate smell, viscous on average, adhesive, with an exceptional detaching and anti-welding power. It has a high stability to ageing.
Application
Indicated in the most severe operations of drawing and punching, at very high pressures and high and complex deformation, of high-alloy steels, such as nickel-chromium and chromium-manganese sheet metal, stainless steel, etc. .., with thickness up to 2 mm.
Data do not constitute any specification.
X-DRAW 220 XP
Oil for drawing and shearing operations of ferrous materials, with very strong anti-welding properties, particularly suitable for very hard stainless steel, used for complex geometries deep-drawing operations and when high-quality finishes are required.
Free from mineral oil, it’s obtained from totally synthetic bases, characterized by an exceptional “viscous-elastic” response to loads, mixed with anti-welding additives based on:
- Active/inactive sulfurized compounds;
- Sulfur-phosphorus compounds;
- Natural and synthetic greasing agents;
- Friction modifiers additives;
- Anti-corrosion and antioxidants agents.
They exert a synergistic action one another creating an absolutely unique product that guarantees:
- An outstanding and unique detaching and anti-welding power;
- Glossy surfaces;
- Duration of dies and pieces;
- Moderate odor;
- Hygienic compatibility
- It is free from chlorine and its derivatives.
Application
Particularly severe machining operations of metal-forming of highly resistant highly alloy and stainless ferrous materials, drawing, deep drawing and shearing, etc.
Data do not constitute any specification.
X-DRAW BIO 100
This is a neat cutting oil. It’s designed for machining, milling, boring, tapping, moulding, bossing, shearing, and other operations when there is a need for a product with a high EP power.
It does not contain mineral oils. It is made up of synthetic esters mixed with active/inactive sulphur-containing compounds, greasing agents, sulphur-and-phosphorus-containing additives, antioxidants and metal passivators. Working synergistically, these ingredients ensure:
- the absence of fumes or vapours during the machining operations;
- a high flashpoint and absolute safety;
- an excellent fluidity, even at low temperature and a superb wetting power, thanks to which the oil spreads out over the metallic surface quickly and uniformly;
- outstanding greasing, EP and detaching power, for high quality finish;
- good resistance to oxidation and rust;
- good antiwear properties;
- an excellent antiwelding power.
This product does not contain chlorine or chlorinated compounds.
Application
X-DRAW BIO 100 is specifically designed for machining operation – including very heavy operations – through minimal lubrication.
Data do not constitute any specification.
X-DRAW BIO 100 LC
It ‘a neat cutting oil, free from mineral oil, formulated to operations of tapping, stamping, deep drawing, fine blanking, high strength steels and stainless steel, when it is required a product with a very high power EP.
E ‘consists of synthetic esters mixed base with active / inactive sulfuric compounds, greasing, sulfuric-phosphorus additives, antioxidants and metal passivators, that by exercising a strong synergistic action between them, guarantee:
- The absence of fumes and vapour formation in the works;
- A high flash point for absolute security operations;
- Excellent smoothness even at low temperatures and exceptional wetting power, for which the oil is dispersed on the metal surface quickly and uniformly;
- Great power untuosante, EP lubricating and release agent for quality finishes;
- Good resistance to oxidation and rust;
- Good anti-wear;
- A great cutting power antisaldante.
The product is free of chlorine and chlorinated compounds. Oil for extrusion presses of ferrous materials in a single stage or in multiple stages for the production of screws and bolts also with internal hexagon and with internal multiple toothing.
Application
X-DRAW BIO 100 LC is a product specifically formulated for machining also very demanding fine blanking <10 mm thick, stamping and cold forming of sheet metal
Data do not constitute any specification.
X-DRAW BIO 160 MV
It is a cutting neat oil, free from mineral oil and formulated for tapping, drawing, pressing and thin shearing of high-resistant and stainless steels, when a product with high EP power is required.
It is made from synthetic-based esters in mixture with active/inactive sulphur compounds, greasy agents, sulphur-phosphor additives, anti-oxidant and metallic passivator, which guarantee:
- No fumes and vapours while working;
- High flash point for absolute safe operations;
- Excellent fluency, even at low temperature and excellent wetting power, which allow the oil to disperse on the metallic surface quickly and uniformly;
- Excellent greasing, EP and lubro-detatching power, in order to have high-quality finishing;
- Good resistance to oxidation and rust;
- Good anti-wear power;
- Excellent anti-welding cutting power.
The product is free from Chlorine and Chlorine compounds.
Application
X-DRAW BIO 160 MV is especially formulated for mechanical operations, even very hard, of thin thickness shearing (from 1 to 20 mm), drawing and sheet cold deformation.
Data do not constitute any specification.
X-DRAW BIO 160 TF
È un olio da taglio intero, esente da olio minerale, formulato per operazioni di maschiatura, stampaggio, imbutitura, tranciatura fine, di acciai ad alta resistenza ed inox, quando sia richiesto un prodotto con un potere EP estremamente elevato ed esclusivo. È costituito da esteri di base sintetici in miscela con composti solforati attivi/inattivi, untuosanti, additivi solfo-fosforati specifici, antiossidanti e passivatori metallici, che, esercitando tra loro una forte azione sinergica, specificatamente studiata ed efficace, garantiscono:
– assenza di fumi e formazioni di vapori in lavorazione;
– un elevato punto di infiammabilità per oprazioni in assoulta sicurezza;
– un’ottima scorrevolezza anche a basse temperature ed un’eccezionale potere bagnante, per cui l’olio si disperde sulla superficie metallica in modo rapido ed uniforme;
– ottimo potere untuosante e lubro-distaccante ed eccezionale potere EP per finiture di massima qualità;
– eccellente resistenza all’ossidazione ed alla ruggine;
– ottimo potere antiusura ed antisaldante di taglio.
Il prodotto è esente da cloro e composti clorurati.
Applicazione
X-DRAW BIO 160 TF è un prodotto specificatamente formulato per lavorazioni meccaniche anche molto gravose di tranciatura fine con spessore: –
I dati riportati non costituiscono specifica.
X-DRAW BIO 40 ST
Neat oil for forming, drawing and shearing, etc., high-resistant alloy steel and stainless steel sheets and strips, used when it’s required a product with a high EP power and anti-seizing and detaching characteristics, for very severe drawing operations of geometrically complex pieces.
It is based on natural oils, refined thanks to a unique method, mixed with active-inactive and complex sulfur compounds, which exert a strong synergic action each other.
It provides:
- very high greasing and detaching power high quality finishes, even with hard materials;
- excellent resistance to oxidation, rust and formation of sludge and solid and sticky residuals, thanks to a special and unique formulation;
- excellent anti-wear properties ensuring the protection of molds;
- no smokes and vapours during the process;
- high flashpoint, for completely safe operations;
- excellent smoothness, even at low temperatures, and wetting power, so that the oil spreads rapidly and uniformly on the metallic surface;
- low temperature of workpieces;
- complete biodegradability;
- maximum tolerance by operators, since it does not contain any harmful and irritant components.
The product is free from chlorinated compounds and polycyclic aromatic hydrocarbons (PAHs).
Application
All cold forming operations of ferrous materials and alloy steels.
Data do not constitute any specification.
X-DRAW BIO 250 TF
It is a cutting neat oil, free from mineral oil and formulated for tapping, drawing, pressing and thin shearing of high resistant and stainless steels, when a product with very high and exclusive EP power is required.
It is made from synthetic-based esters in mixture with active/inactive sulphur compounds, greasy agents, specific sulphur-phosphor additives, anti-oxidant and metallic passivator, which guarantee:
- No fumes and vapours while working;
- High flash point for absolute safe operations;
- Excellent fluency, even at low temperature and excellent wetting power, which allow the oil to disperse on the metallic surface quickly and uniformly;
- Excellent greasing and lubro-detatching power and outstanding EP power, in order to have high-quality finishing;
- Excellent resistance to oxidation and rust;
- Excellent anti-wear and cutting anti-welding power.
The product is free from Chlorine and Chlorine compounds.
Application
X-DRAW BIO 250 TF is especially formulated for mechanical operations, even very hard, with thickness:
- From 1 to 15 mm for ferrous materials
- From 1 to 10 mm for stainless steels
It is also formulated for sheet cold deformation and drawing.
Data do not constitute any specification.
X-DRAW GL 15
X-DRAW GL 15 is a gel, specific for stainless steel tubes curving.
Its particular formulation, free from mineral oil, gives to the product excellent environmental and hygienic-sanitary compatibility characteristics.
The product, after having used it, tends to dry, leaving the pieces well cleaned and allowing to weld without fumes.
Data do not constitute any specification.
X-DRAW GL 45
X-DRAW GL 45 is a gel, specific for stainless steel tubes curving. Its particular formulation, free from mineral oil, with E.P. and anti-wear additives, gives to the product excellent environmental and hygienic-sanitary compatibility characteristics.
The product, after having used it, tends to dry, leaving the pieces lightly protected with a tender film, which has lightly corrosion-passivator properties. This film can be removed with a weak flow of water.
Data do not constitute any specification.
X-PRESS 89 LC
It’s an oil for extrusion of ferrous metals consisting of a highly selected mineral base oil and additives for Extreme Pressure base of active sulfuric compounds and Inactive, sulfuret and lubricity, which exercise between them an effective synergistic effect.
In addition, it is free from chlorinated compounds and contains anti-corrosive agents and antioxidants.
Guarantees:
- A long-term oil charge without formation of sludge, residues, lacquers, paints, etc.;
- An ultra-low smokiness;
- A very moderate odour in the works;
- Excellent power and EP release.
Application
Oil for extrusion presses of ferrous materials in a single stage or in multiple stages for the production of screws and bolts also with internal hexagon and with internal multiple toothing.
Data do not constitute any specification.
X-DRAW V 6205 SY
X-DRAW V 6205 SY is a fluid used for pressing and blanking of ferrous and non-ferrous material, indicated especially for blanking and light drawing when you want to obtain particularly clean pieces.
X-DRAW V 6205 SY is obtained from a mineral fluid evaporating, highly chosen and hydrogenated, with very moderated odour base, in mixture with additives which are constituted by:
- From synthetic origin greasy;
- Additives which change the friction;
- Anti-corrosives and anti-oxidants.
These explicate among them a synergic action, which allow to obtain a product which guarantees:
- An excellent anti-weld and detaching power;
- Lustre of surfaces;
- Duration of the stamps and the pieces;
- Low odour;
- Hygienic-sanitary compatibility.
After the evaporation of the flying part, the product leaves on the piece an oily slightly film, stable in the time.
Application
Deformation and blanking of ferrous material, aluminium, copper and its alloys. The product has been designed for air conditioner fins and to compact copper plaits.
Data do not constitute any specification.
X-DRAW V 6220
E’ un fluido da utilizzare per stampaggio e tranciatura di materiali ferrosi, particolarmente indicato per lavorazioni di tranciatura e imbutitura medioleggera, quando si vogliono ottenere pezzi particolarmente puliti. E’ ottenuto da una base minerale fluida, evaporabile, altamente selezionata ed idrogenata, di odore molto moderato, in miscela con additivi costituiti da:
- untuosanti di origine naturale e sintetici;
- modificatori di attrito;
- anticorrosivi ed antiossidanti.
Questi esplicano tra loro un’azione sinergica che consente di ottenere un rodotto che garantisce:
- un eccellente potere distaccante-antisaldante;
- lucentezza delle superfici;
- durata degli stampi e dei pezzi;
- bassi odori;
- compatibilità igenico-sanitaria.
Applicazione
Lavorazioni meccaniche di deformazione e tranciatura di materiali ferrosi, alluminio, rame e sue leghe.
I dati riportati non costituiscono specifica.
X-PRESS 110
t is an oil for extrusion of ferrous metals consisting of a highly selected paraffinic mineral base and additives for Extreme Pressure base of active sulfuric compounds and Inactive, sulfuret and lubricity, which exercise between them an effective synergistic effect.
It is free from chlorinated compounds and contains anti-corrosive, anti-oxidant agents and metallic passivators.
Features:
- A long-term oil charge without formation of sludge, residues, lacquers, paints, etc.;
- A very high flash point;
- A very low tendency to oil mist and smoke formation;
- A very moderate odour while working;
- Excellent detaching and anti-welding power and EP release.
Application
Oil for extrusion of strong alloyed and stainless steels, in single or multiple stadium presses, in particular SACMA and NATIONAL, for screws and bolts production, even with internal hexagon, internal multiple toothing and complex shape pieces, when submitted to the hardest loads.
The product is also suitable for lubrication of presses ways and movements.
Data do not constitute any specification.
